● Understanding Aluminum Storm Windows
>> Essential Tools and Materials
>> Step 1: Remove the Window Frame
>> Step 3: Remove Broken Glass
>> Step 4: Measure for Replacement Glass
>> Step 5: Disassemble Frame (if necessary)
>> Step 7: Reassemble the Frame
>> Step 8: Reinstall Weather Stripping
● Additional Repairs for Common Issues
● Regular Maintenance Practices
● FAQ
>> 1. How often should I inspect my aluminum storm windows?
>> 2. Can I replace just one pane of glass in a storm window?
>> 3. What type of sealant should I use for my aluminum storm windows?
>> 4. Is it worth repairing old aluminum storm windows?
>> 5. How do I prevent rust on my aluminum storm windows?
Aluminum storm windows offer an extra layer of protection against the elements, enhancing insulation and potentially reducing energy costs. They are known for their durability and resistance to rust, making them a popular choice for homeowners. However, like all components of a house, aluminum storm windows can suffer damage over time. Common issues include broken glass, damaged frames, and worn weather stripping. Regular maintenance and timely repairs are essential to extend the life and functionality of these windows.
Aluminum storm windows are typically installed on the exterior of a home's primary windows. Their main purpose is to provide additional insulation, which helps to keep homes warmer in the winter and cooler in the summer. Besides insulation, these windows also offer a barrier against harsh weather conditions, protecting the underlying windows from damage.
Before starting any repairs, it's important to identify the most common problems associated with aluminum storm windows. These include:
- Broken Glass: Cracks or shatters in the glass pane are among the most frequent issues.
- Damaged Frames: Aluminum frames can become bent or corroded, which can compromise the window's structural integrity.
- Weather Stripping Wear: Over time, weather stripping can become cracked or worn, leading to drafts and reduced energy efficiency.
- Faulty Hardware: Latches and slide bolts can break, preventing the window from operating correctly.
To effectively repair aluminum storm windows, it is necessary to gather the right tools and materials:
- Safety goggles and gloves
- Screwdriver set (flathead and Phillips)
- Utility knife
- Pliers
- Rubber mallet
- Measuring tape
- Replacement glass pane (cut to size)
- Glazing spline or putty
- Weather stripping (if needed)
- Caulk or sealant
- Clamps
Follow these steps to repair your aluminum storm window frame effectively:
Begin by carefully removing the storm window from its frame. This usually involves pressing in on the latches at the bottom of the window and sliding the window up and out of its track.
Once the window is removed, thoroughly inspect the glass and frame for any damage. Look for cracks in the glass, corrosion on the frame, and wear on the weather stripping.
If the glass is broken, carefully remove any remaining shards using pliers. Wear safety gloves to protect your hands from cuts.
Measure the opening where the glass will fit. Ensure the new piece of glass is slightly smaller than the opening to allow for expansion. Typically, making it about 1/8 inch shorter in both dimensions is adequate.
Most storm window frames are machine-pressed together and may need to be drilled out to separate the frame. Secure one of the side frames to your work surface with a clamp. Place a wood block on the inside corner of the frame and tap it with a hammer to separate the frames. Repeat this on all four corners.
Insert the new glass into the frame. Secure it using a glazing spline, pressing it into the groove around the glass with a spline roller or your fingers. Trim any excess spline with a utility knife.
If your storm window uses screws, reinsert them at each corner of the frame. If it uses clips instead of screws, reattach those carefully. When reassembling the frame, align the corner keys on the top frame with the corners of the sides and gently tap the frame onto the glass. Do the same with the bottom frame.
If the weather stripping is worn, remove the old strips carefully. Cut new weather stripping to size and press it into place around the edges of the frame to ensure a tight seal.
Carefully lift the storm window back into its track. Ensure it is seated properly before securing it with latches.
Besides the standard repairs, here are some techniques to address specific issues to enhance the durability and performance of your aluminum storm windows:
If the aluminum frame is warped or corroded:
- Assess Damage: Determine if minor rust can be sanded down and treated with a rust-inhibiting primer or if major damage requires replacement.
- Repairing Dents: For small dents, use a rubber mallet to gently tap them back into shape. For deeper scratches, consider using a filler designed for aluminum surfaces before repainting.
- Repainting: Clean the frames thoroughly and apply a suitable exterior paint to help protect against further deterioration if they show signs of oxidation or pitting.
- Prepare the Window: Lay the storm window on a towel-covered surface and clamp it down for stability.
- Drill Out the Indentations: Use a 3/32 drill bit to drill out the indentations in the aluminum that hold the corner piece in place. There are typically four indentations on the front and four on the back.
- Remove Weather Stripping: Remove the weather strip to access the set spots on the back side.
- Knock Out the Broken Piece: Use a hammer and screwdriver to knock out the broken corner piece.
- Install the New Corner: Slide the new corner into place, ensuring the weather stripping is properly aligned.
- Set the Corner: Use a nail punch to set the new corner in place. Do one side and then flip it over to do the other side.
- Reinstall Weather Stripping: Slide the weather strip back into place.
- Remove Screens and Windows: Take the screens out annually and lay them down on a flat surface to clean them off with a soft bristle brush.
- Remove Old Glazing: Remove any broken glazing from the sash. If there are metal keys inside the frame, remove the screws. If the corners are crimped, take the vinyl spines out with an awl.
- Install New Glazing: Ensure the new glazing is about 2 mm smaller than the inside frame to allow for expansion. Lay the glazing vinyl onto the glass and press it directly into the frame. Assemble the corners last.
Regular maintenance is key to prolonging the life of aluminum storm windows. Here are some practices to follow:
- Annual Cleaning: Annually, remove the screens and clean them with a soft bristle brush. Clean the frames as well to ensure they are in good working condition.
- Inspect Vent Holes: Check the vent holes between the exterior windowsill and the bottom of the aluminum frame. Ensure these holes are open to allow moisture-filled air to escape and prevent water damage.
- Clean Sash Slides: Remove the sash and clean the channels using a stiff bristle brush. Clean the sash frames with steel wool and wipe the sides with a cleaning cloth sprayed with silicone lubricant before reinstalling.
- Seal All Edges: Ensure all edges of the aluminum frame are sealed to prevent leaks. Use a silicone sealant for a strong and waterproof seal.
Repairing aluminum storm windows involves several steps, from identifying common issues to performing detailed repairs and regular maintenance. By following the guidelines provided, homeowners can effectively maintain their storm windows, ensuring they remain functional, energy-efficient, and aesthetically pleasing for years to come. Regular inspections and timely repairs not only extend the life of the windows but also contribute to the overall comfort and value of the home.
It is recommended to inspect your aluminum storm windows at least once a year. Regular inspections can help identify potential issues early, preventing more extensive and costly repairs.
Yes, you can replace just one pane of glass in a storm window. Measure the opening accurately and cut a new piece of glass to the correct size. Follow the steps for removing broken glass and installing the new pane.
A silicone sealant is recommended for aluminum storm windows. Silicone provides a strong, waterproof seal that can withstand various weather conditions.
In many cases, repairing old aluminum storm windows is worth the effort. Repairs can extend the life of the windows and improve their energy efficiency. However, if the frames are severely damaged or corroded, replacement may be a more cost-effective solution.
To prevent rust on aluminum storm windows, regularly clean the frames and apply a rust-inhibiting primer and paint. Ensure that any scratches or dents are promptly repaired to prevent moisture from penetrating the aluminum. Keeping the windows dry and well-maintained will significantly reduce the risk of rust.
